S1102-01Systems
MSI S1102 1U AMD Ryzen and EPYC 4005 Server
1U single-socket platform for AMD EPYC 4004/4005 and Ryzen 7000/9000 series processors, built for power efficiency and cost-optimized performance, with integrated NVMe, SATA and SAS support and versatile cooling via vapor chamber or liquid cooling modules.
GPU Partner supplies the S1102 as a barebone platform for integration, configured to order with CPUs, memory, storage, and accelerators. Key platform capacities: 4 memory slots; 1500W power. Full specifications are listed below and in MSI's product portfolio.
MSI part numbers for this platform: S1102-01, S1102-02. These differ mainly in drive-bay and RAID configuration; contact us to confirm the right SKU for your build.
- Price
- available on request
- Form Factor
- 1U Rackmount
- Product Class
- Mainstream
- CPU Support
- AMD Ryzen 7000/9000
- Also Supports
- EPYC 4004/4005
- Sockets
- 1 (single-socket)
- Max CPU TDP
- Up to 170W
- Cooling Options
- Vapor chamber / liquid
- DIMM Slots
- 4x RDIMM
- Speed (1DPC)
- Up to 5600MT/s
- Speed (2DPC)
- Up to 3600MT/s
- Front Bays
- 4x 3.5"/2.5"
- Bay Interface
- SATA 3.0 / SAS
- Internal Bays
- 2x 2.5" SATA 2.0
- M.2 Slots
- 2x 2280/22110
- M.2 Interface
- PCIe 4.0 x4 NVMe
- Single-Wide
- Up to 1x SW
- Onboard LAN
- 2x 10GbE
- TPM
- TPM 2.0 module
- Wattage
- 1500W
