Supermicro X11SCH-LN4F Single LGA-1151 Micro-ATX Server Motherboard
MBD-X11SCH-LN4FAvailable to order
Supermicro X11SCH-LN4F micro-ATX server motherboard on a single Socket H4 (LGA-1151) supporting Intel Xeon E-2100 and E-2200 processors and 8th/9th Gen Core i3, Pentium and Celeron parts up to 95W TDP. Intel C246 chipset with four DIMM slots taking up to 128GB of DDR4-2666 ECC UDIMM. Eight SATA3 ports with RAID 0/1/5/10, two M.2 PCIe 3.0 x4 M-key sockets, two PCIe 3.0 x8 slots and four Intel i210 Gigabit LAN ports — the quad-NIC layout that suits edge routing, firewall and appliance builds.
- Form Factor
- Micro-ATX
- Chipset
- Intel C246
- Socket
- LGA-1151 (H4)
- Xeon Support
- E-2100 / E-2200
- Core Support
- 8th / 9th Gen
- Max TDP
- 95 W
- DIMM Slots
- 4
- Max Capacity
- 128GB
- Memory Type
- DDR4-2666 ECC
- Module Type
- UDIMM
- PCIe Slot 1
- x8 in x16 (Gen3)
- PCIe Slot 2
- PCIe 3.0 x8
- M.2 Sockets
- 2× NGFF
- M.2 Interface
- PCIe 3.0 x4
- M.2 Lengths
- 2280, 22110
- SATA
- 8× SATA3 6 Gb/s
- SATA RAID
- 0, 1, 5, 10
- SuperDOM
- 2, built-in power
- LAN
- 4× GbE (Intel i210)
- USB 3.1 Gen 2
- 2 rear
- USB 3.1 Gen 1
- 3 (1 Type-A)
- USB 2.0
- 6 (2 rear)
- Video
- 1× VGA
- Serial
- 2× COM
- IPMI
- 2.0 with KVM
- Dedicated LAN
- Yes
- TPM
- Header
Board
Processor
Memory
Expansion
Storage & I/O
Management
Priceavailable on request
Get a quote
